• All structural dips can be accurately interpreted based on image logs;
• Structural domains may be determined using structural dip trend analysis.

Fault Interpretation

Structural interpretation

Structural Dip & Trends

• Faults can be located on image logs with fault dip and strike estimated;
• It can be also visualized in 2D cross-section view;
• Knowledge about tectonic history & structural background is important when performing fault and structural interpretation.

Structural interpretation

Structural interpretation

Structural interpretation

• Structural interpretation may be performed using interpreted structural dip, domains and fault data;
• Seismic data integration is always possible and preferred. This allows seismic structures be fully calibrated with borehole images;
• Structural risk can be minimized in structurally complex reservoirs, e.g. near-salt, sub-salt, thrust-belt settings.
